Description

Turning length 2500 mm
Control Sinumerik 840 D
Spindle head A 11
Number of tools 48
Circulation diameter over bed slide 750 mm
Circulation diameter over bed 780 mm
C-axis 0.1-30 1/min
Pinole diameter 160 mm
Inner taper MK 5
Tool length - max. 500 mm
Tool weight max. 15 kg
Machine weight approx. 27 t
Space requirement approx. 8.4 x 4.0 x 2.5 m
Technical details: Nominal turning length: 2,500 mm Swing diameter over bed slide: 750 mm Swing diameter over bed: 780 mm Working height: 1,300 mm Spindle head according to DIN 55026: A 11 Bore through: 123 mm Front bearing diameter: 200 mm Oriented spindle stop: 0-359 degrees Drive power at 100/60% ED: 37/45 kW Total speed range: 10-2,500 rpm Number of speed ranges: 2 Speed range I: 10-775 1/min Speed range II: 20–2,500 1/min Max. torque at 60% ED: 2,083 Nm (up to 186 1/min)
