Description

Saw band dimensions 2950x27x0.9 mm
2 speeds 15-100 m/min
Vice opening 285 mm
Cutting area at 90 degrees: square 220 mm
Cutting area at 90 degrees: around 250 mm
Cutting area at 90 degrees: flat 280x220 mm
Cutting area at 60 degrees: around 120 mm
Cutting area at 60 degrees: square 80 mm
Cutting area at 60 degrees: flat 140x100 mm
Cutting area at 45 degrees: around 230/200 mm
Cutting area at 45 degrees: square 200/170 mm
Cutting area at 45 degrees: flat 220x200/200x140 mm
Total power requirement 2.2 kW
Weight 990 kg
Machine dimensions 2500x2230x2050 mm
